| Characteristics | Parameter | Rating 数 |
| Electrical characteristics : | 1-1. Power Requirement | DC Input: 12V ±0.5V |
| 1-2. The angle range of the ball valve -6° ~ 27° |
DC Output: 1V ±0.3V （10K Load） DC Output: 1V +0.6V /-0.4V (Automotive systemload condition) |
|
| 1-3. The angle range of the ball valve 27° ~ 63° |
DC Output: 2.5V ±0.3V (10K Load) DC Output: 2.5V +0.6V/-0.5V (Automotivesystem load condition) |
|
| 1-4. The angle range of the ball valve 63°~ 96° |
DC Output: 4V ±0.3V (10K Load) DC Output: 4V +0.7V/-0.6V (Automotive systemload condition) |
