Wide operating range
Compact size, easy installation
High reliability
Wear-resistant and
high-temperature resistant
No power consumption
Long service life
Fast response
Stable switching operation
Features contact protection
for enhanced safety
|
Parameter |
Rating |
|
Contact Form |
A type (normal open) contact |
|
Magnet Spec. |
Size17.8×9.5×4.5(mm),Surface Magnetic≥3120Gauss |
|
Sensor ON |
20 mm Min. |
|
Sensor OFF |
50 mm Max |
|
Max. Contact Rating |
10W |
|
Max. SwitchingVoltage |
AC 300V |
|
Max. Carrying Current |
AC 2.5A |
|
Max. Switching Current |
AC 0.5A |
|
Initial Contact Resistance |
500 mΩ Max |
|
Insulation Resistance |
108ΩMin. (DC 500V) |
|
Breakdown Voltage |
DC250V Min.(Cut-off Current 1mA,in 1 minute) |
|
Electrical Life |
106 operations Min. (DC 100V, 0.1A，Load R) |
|
Shock Resistance |
30G Max |
|
Vibration Resistance |
Vibration frequency of 10 ~ 55Hz.Amplitude of 1.52 mm at (X, Y, Z), 3directions, 2hours. |
|
Mechanical Life |
107 operations Min.（No load） |
|
Operating Temperature |
-10℃ ~ +80℃ |
|
Operating Humidity |
RH 80% Max |
