| Characteristics | Parameter | Rating |
| Electrical characteristics : | Contact Form | A type (normal open) contact. |
| Max. Contact Rating |
10 W |
|
| Max. Switching Voltage |
DC 100V |
|
| Max. Carrying Current |
DC 1.0A |
|
| Detection output level |
Output Low level when Detected water inof sensitivity range ：<=0.5V |
|
| Detection sensitivity | Refer to below item4 “The sensitivity teststandard diagram” | |
| Working current | 10mA | |
| Operating Condition： | Operating Temperature | -10℃ ~ +60℃ B12 |
| Operating Liquid | Water | |
