| Parameter | Rating |
| Contact Form | A type (normal open) contact |
| Sensor1 ON/OFF | 12 ± 2 mm |
| Sensor2 ON/OFF | 88 ± 2 mm |
| Max. Contact Rating | 10W |
| Max. Switching Voltage | DC 100V |
| Max. Carrying Current | DC 1.0A |
| Max. Switching Current | DC 0.5A |
| Initial Contact Resistance | 800 mΩ Max |
| Insulation Resistance | 108Ω Min. (DC 500V) |
| Electrical Life | 10⁶ operations Min. (DC 100V, 0.1A, Load R) |
| Shock Resistance | 30G Max |
| Vibration Resistance | Vibration frequency of 10 ~ 55Hz. Amplitude of 1.52 mm at (X, Y, Z), 3directions, 2hours. |
| Mechanical Life | 10⁶ operations Min. (No load) |
| Wire Strength | The wire is hanging a weight of 3 kg for 1 minute or above. The wire should not be come out. |
| Operating Temperature | -10℃ ~ +80℃ |
| Operating Humidity | RH 95% Max |
| Heat-Shock | -20℃ ~ +70℃ |
