| Characteristics | Parameter | Rating | |
|
Electrical characteristics: |
Power supply voltage |
12 to 24 VDC+/-10% ripple (p-p) 5 % max. |
|
|
Control output |
Output type | Open Drain output | |
| Load power supply voltage | 5 to 24 V DC | ||
| Load current | 100 mA max. | ||
| Residual voltage |
at 100 mA load current: 0.8 V max. at 40 mA load current: 0.4 V max. |
||
| Current consumption |
Average value: 30 mA max. Peak: 80 mA max. |
||
| Indicator | Light indicator | ||
| Operation mode | Dark-ON/Light-ON (selectable) | ||
|
Operating Condition: |
Ambient temperature |
Operating: -10 to 55℃ (with no freezing or condensation) Storage: -25 to 65℃ (with no freezing or condensation) |
|
| Ambient humidity |
Operating: 5 to 85 % (with no condensation) Storage: 5 to 95 % (with no condensation) |
||
