| Characteristics | Parameter | Rating |
| Electrical characteristics : | 1-1. Power Requirement | 5V DC +/-0.1V |
| 1-2. Output Signal | High - and low - level output | |
| 1-3. Detection Object | Tap water | |
| 1-4. Detection output level |
Output High level when Detected water outof sensitivity range |
|
| 1-5. Detection output level |
Output Low level when Detected water inof sensitivity range |
|
| 1-6. Detection sensitivity | Refer to below item4 “The sensitivity teststandard diagram” | |
| 1-7. Working current | 10mA | |
| Mechanical characteristics： | 1-8. Waterproof level | IP67 |
| 1-9. Line length |
1 FT |
|
| Operating Condition： | 1-10. Temperature of the liquid | 0 - 60°C |
| 1-11. Storage temperature | 0 - 70°C | |
| 1-12. Service |
Compatible detection for tap water， 1-12. Service spring water, distilled water, |
