| Parameter | Rating |
| Infrared Sensor | Dual Element Detection |
| Power Supply | 9-16V DC, 12V |
| Current Consumption | 10mA (12V) |
| Alarm Output | NC/NO 30VDC, 0.2A Max |
| Alarm Duration | 1s/min |
| Pulse Count | 1/2/3, Optional |
| Tamper Switch | NC No Voltage Output |
| Walk Test LED | LED Optional |
| Anti-interference | 20V/m (10-1000MHz) |
| Detection Speed | 0.3-3.0m/s |
| Installation Height | 2.3m, Typical Value |
| Ambient Humidity | 95%RH Max |
| Operating Temperature | -10℃ ~ +60℃ (-4°F ~ 140°F) |
| Dimensions | 114×60×45mm |
