| Model No. | PBT-30 | PBT-40 | PBT-60 | PBT-80 | PBT-100 |
| Protection Range | 30m | 40m | 60m | 80m | 100m |
| Distance Allowance | 300m | 400m | 600m | 800m | 1000m |
| Detection System | Alarm when 2 beams cut simultaneously | ||||
| Response Time | 35 ~ 500ms | ||||
| Operating Voltage | DC 9.8~25V/DC(12V recommended) | ||||
| Current Consumption Max | 45mA | 50mA | 55mA | 60mA | 65mA |
| Optical Axis Horizontal Adjust | 180° ( ±90° ) | ||||
| Optical Axis Vertical Adjust | 10° ( ±5° ) | ||||
| Alarm Output | Relay contact output 1C, NC/NO, Contact rating AC, DC24V, 0.2A MAX | ||||
| Tamper Output | Output 1B, Contact rating DC 30V 0.1A MAX | ||||
| Collimator | View Finder | ||||
| Operation Temperature | -25℃~+60℃ | ||||
| Output Dimension | 170(H) X 65(W) X 70(D) mm | ||||
| Weight | 800g | ||||
