Parameter

Rating

Contact Form

A type (normal open) contact

Sensor ON

10 °+ 10/-5°

Sensor OFF

20°+ 15/-5°

Max. Contact Rating

10W

Max. SwitchingVoltage

DC 100V

Max. Carrying Current

DC 1.0A

Max. Switching Current

DC 0.5A

Initial Contact Resistance

0.2Ω Max

Insulation Resistance

108ΩMin. (DC 500V)

Breakdown Voltage

AC1500V Min.(Cut-off Current 1mA,in 1 minute)

Electrical Life

107operations Min. (DC 6V, 10mA，Load R)

Shock Resistance

294m/s2Max

Vibration Resistance

Vibration frequency of 10 ~ 55Hz.Amplitude of 1.52 mm at (X, Y, Z), 3directions, 2hours.

Operating Temperature

-30℃ ~ +80℃

Operating Humidity

RH 95% Max
